11 mark
The graph below shows a reaction profile for the reaction between methane and oxygen.
What does the label X represent?
Activation energy
Overall energy change
Reactants
Progress of the reaction
Did this page help you?
Exothermic & Endothermic Reactions (Cambridge O Level Chemistry)
Exam Questions
3 hours33 questions
21 mark
What is the reading on the following thermometer?
28.3 oC
28.6 oC
29.2 oC
28.5 oC
Did this page help you?
31 mark
A student adds a small amount of ammonium chloride to a beaker of water. The temperature of the water decreases from 21 oC to 17 oC.
Which type of reaction has occurred and why?
| type of reaction | reason | |
| A | exothermic | heat is released |
| B | exothermic | heat is absorbed |
| C | endothermic | heat is released |
| D | endothermic | heat is absorbed |
Did this page help you?
41 mark
The energy level diagram below shows the relative energies of the reactants and products in a reaction.
Which row correctly describes the type of reaction and corresponding energy change?
| type of reaction | energy change | |
| A | endothermic | heat is released |
| B | endothermic | heat is absorbed |
| C | exothermic | heat is released |
| D | exothermic | heat is absorbed |
Did this page help you?
51 mark
Calcium and hydrochloric acid react to produce calcium chloride and hydrogen gas. The energy level diagram for the reaction is shown below.
Which statement about this reaction is not correct?
The temperature of the surroundings increases.
The reaction is endothermic.
The products have less energy than the reactants.
Energy is released during the reaction.
Did this page help you?
11 mark
Which of the following processes is endothermic?
Reacting sodium with water.
The use of petrol in an engine.
Distilling crude oil.
Burning fossil fuels.
Did this page help you?
21 mark
In all chemical reactions, bonds in the reactant species are broken and new bonds are formed in the products. Which statement is correct?
Bond breaking requires energy and is thus an exothermic process.
Bond breaking requires energy and is thus an endothermic process.
Bond breaking releases energy and is thus an exothermic process.
Bond breaking releases energy and is thus an endothermic process.
Did this page help you?
3
1 mark
1 markWhich is true about chemical energy changes?
| Reaction type | Energy flows | Temperature of surroundings | |
| A | exothermic | to the surroundings | increases |
| B | exothermic | from the surroundings | decreases |
| C | endothermic | to the surroundings | decreases |
| D | endothermic | from the surroundings | increases |
Did this page help you?
41 mark
1 markThe reaction profile for making nitrogen monoxide, NO, is shown below:
What is the activation energy for this reaction?
+140 kJ
+180 kJ
+320 kJ
-330 kJ
Did this page help you?
51 mark
Endothermic reactions can be used in emergency sports injury treatment packs.
What is true about these packs?
Absorb energy from the surroundings and transfer it to the injury
Can be re-used
Usually contain ammonium nitrate and water in separate compartments
Cause the temperature of the surroundings to increase
Did this page help you?
61 mark
An endothermic reaction has an activation energy of x.
Which reaction pathway diagram is correct for this reaction?
Did this page help you?
71 mark
The formation of liquid water from hydrogen and oxygen may occur in three stages.
| 1 | 2H2(g) + O2(g) → 4H(g) + 2O(g) |
| 2 | 4H(g) + 2O(g) → 2H2O(g) |
| 3 | 2H2O(g) → 2H2O(l) |
Which stages are endothermic?
1, 2 and 3
1 only
1 and 3
2 only
Did this page help you?
11 mark
Chlorine and ethane react together in an exothermic reaction to produce chloroethane and hydrogen chloride. The equation for the reaction is shown below.
C2H6 + Cl2 → C2H5Cl + HCl
The table below shows the relevant bond energies.
| bond | bond energy / (kJ / mol) |
| CーCl | + 340 |
| CーC | + 350 |
| CーH | + 410 |
| ClーCl | + 240 |
| HーCl | + 430 |
What is the energy change for the reaction between chlorine and ethane?
-120 kJ / mol
-1020 kJ / mol
+120 kJ / mol
+1020 kJ / mol
Did this page help you?
21 mark
The production of ammonia involves the exothermic reaction between nitrogen and hydrogen. The equation for the reaction is shown.
N2 + 3 H2 → 2 NH3
The table shows the bond energies.
| bond | bond energy / (kJ / mol) |
| NーH | +390 |
| HーH | +436 |
| N☰N | +945 |
What is the energy released during the reaction?
-230 kJ / mol
-1025 kJ / mol
-87 kJ / mol
+87 kJ / mol
Did this page help you?
31 mark
Chlorine and hydrogen react in an exothermic reaction producing hydrogen chloride. The equation for the reaction is shown.
Cl2 + H2 → 2 HCl
The table shows some of the bond energies involved. The total energy change for this reaction is -184 kJ / mol.
| bond | bond energy / (kJ / mol) |
| HーCl | +430 |
| HーH | +436 |
| ClーCl | - |
What is the energy of the Cl─Cl bond?
-170 kJ / mol
+240 kJ / mol
+170 kJ / mol
-240 kJ / mol
Did this page help you?
41 mark
Methane combusts in oxygen as shown producing an energy change of -890 kJ / mol.
CH4 + 2O2 → CO2 + 2H2O
The table shows some of the bond energies involved.
| bond | bond energy / (kJ / mol) |
| HーO | +460 |
| O＝O | +496 |
| CーH | +410 |
| C＝O | - |
What is the energy of the C＝O bond?
-155 kJ / mol
+333 kJ / mol
-840 kJ / mol
+841 kJ / mol
Did this page help you?
51 mark
An energy level diagram is shown below.
Which row is correct for the points labelled 1, 2 and 3?
| 1 | 2 | 3 | |
| A | activation energy | energy change | reactants |
| B | energy change | activation energy | products |
| C | energy change | activation energy | reactants |
| D | activation energy | energy change | products |
Did this page help you?
