Current, Potential Difference, Resistance & Power (Edexcel International AS Physics)

Exam Questions

43 mins10 questions

Select a question set to download for
Current, Potential Difference, Resistance & Power

Select an answer set to view for
Current, Potential Difference, Resistance & Power

Easy
Medium
1a
Sme Calculator3 marks

The circuit diagram shows a resistor of resistance 270 Ω connected to a battery of e.m.f. 9.0 V. The battery has an internal resistance of 15 Ω.

q12-wph12-02-june-2021-edexcel-int-as-a-level-phy

Explain why the reading on the voltmeter is less than 9.0 V when the switch is closed.

How did you do?

1b
Sme Calculator3 marks

Calculate the reading on the voltmeter when the switch is closed.




Reading on voltmeter = ..............................

How did you do?

1c
Sme Calculator2 marks

The switch remains closed and 12 C of charge flows through the battery.

Calculate the decrease in the chemical energy store of the battery.



Decrease in chemical energy store = ...........................

How did you do?

Did this page help you?

1a
Sme Calculator3 marks

Two resistors of resistance R subscript 1 and R subscript 2 are connected in parallel in a circuit.

Derive a formula for the total resistance R subscript straight T of the combination.

How did you do?

1b
Sme Calculator3 marks

The diagram shows a combination of five resistors, M, N, O, P and Q. Each resistor has a resistance of 5.0 Ω.

q15b-wph12-02-oct-2021-edexcel-int-as-and-a-level-phy

i)
Show that the resistance between points A and B is about 3 Ω.
(3)
ii)
A student is told to modify the combination of resistors so that the combined resistance between A and B is greater than 5.0 Ω. She cannot change the arrangement of the resistors, but she can replace one of the 5.0 Ω resistors with a 20.0 Ω resistor.

Explain, without further calculations, which of the five resistors should be replaced.
(2)

How did you do?

Did this page help you?

2a
Sme Calculator3 marks

The circuit diagram shows three identical resistors and two switches, X and Y.
The battery has negligible internal resistance.

q18-wph12-02-june-2021-edexcel-int-as-a-level-phy

Each resistor consists of a wire of diameter 0.181 mm and length 55.0 cm. At room temperature, the resistivity of the wire is 1.10 × 10−6 Ω m.

Show that the resistance of one resistor at room temperature is about 24 Ω.

How did you do?

2b
Sme Calculator4 marks

A student suggests that the maximum power output from the resistors in this circuit will be greater than 12 W.

Assess whether the student’s suggestion is correct.

How did you do?

2c
Sme Calculator6 marks

Switch X was open and switch Y was closed.

i)
Calculate the number of conduction electrons passing through the resistor every second immediately after switch Y was closed.

(3)




Number of electrons = ............................

ii)
After switch Y had been closed for a few minutes, the power dissipated by the resistor decreased.

Explain why.

(3)

How did you do?

Did this page help you?

3a
Sme Calculator6 marks

A student set up the circuit shown.

q17-wph12-02-jan-2022-edexcel-int-as-a-level-phy

Calculate the number of electrons passing point X each second.







Number of electrons in one second = ..............................

How did you do?

3b
Sme Calculator4 marks
Another resistor, Y, is added to the circuit as shown.

q17b-wph12-02-jan-2022-edexcel-int-as-a-level-phy

The student wrote the following statement.

When resistor Y is added, the resistance of the parallel section
increases, the resistance of the whole circuit increases, and so, by
P = I2R, the power dissipated by the whole circuit also increases.



Evaluate the student’s statement.

How did you do?
