Refraction, Reflection & Polarisation (Edexcel International A Level Physics): Exam Questions

42 mins7 questions

Select a download format for Refraction, Reflection & Polarisation

Scroll for more

Select an answer set to view for
Refraction, Reflection & Polarisation

1a
Sme Calculator3 marks

Diamonds, cubic zirconia and silicon carbide can be used as gemstones in jewellery.

The speed of light in these materials is shown in the table.



diamond

cubic zirconia

silicon carbide

speed of light/ms−1

1.24 × 108

1.39 × 108

1.15 × 108

In order to identify the material used, a ray of light is directed towards a boundary between air and the gemstone.

q11a-wph12-02-oct-2021-edexcel-int-as-and-a-level-phy

Deduce the material used for the gemstone.

How did you do?

1b
Sme Calculator6 marks

Diamonds are cut into different shapes so that they ‘sparkle’ when light shines on them.

The diagram shows a ray of light entering a diamond and incident on a boundary between diamond and air.

q11b-wph12-02-oct-2021-edexcel-int-as-and-a-level-phy

i) Add to the diagram to show the path of the ray of light as it leaves this boundary. Your answer should include a calculation.

(4)

ii) Explain what would happen to the ray at this boundary if the material used was silicon carbide instead of diamond.

(2)

How did you do?

Did this page help you?

2a
Sme Calculator5 marks

The refractive index of glass varies with the colour of light.

refractive index of glass for red light = 1.513

refractive index of glass for violet light = 1.532

A ray of white light is incident on side AB of a rectangular glass block, as shown.

q13a-wph12-02-june-2021-edexcel-int-as-a-level-phy

The red light and violet light from the incident ray arrive at slightly different points on side CD.

Determine the distance between these points.

Distance between points = ........................

How did you do?

2b
Sme Calculator4 marks

White light is incident on a boundary between glass and air, as shown.

q13b-wph12-02-june-2021-edexcel-int-as-a-level-phy

Explain what happens to the red light and the violet light when meeting the boundary.

Your answer should include calculations.

How did you do?

Did this page help you?

3a
Sme Calculator3 marks

When unpolarised light passes through a polarising filter, the light becomes plane polarised.

Explain the difference between unpolarised and plane polarized light.

How did you do?

3b
Sme Calculator3 marks

An unpolarised light source is directed towards a screen. The intensity of radiation measured at the screen is 1.00 W m−2.

Two polarising filters are placed between the light source and the screen.

Initially there is an angle of 0° between their planes of polarisation, as shown.

q16b-wph12-02-june-2021-edexcel-int-as-a-level-phy

One of the polarising filters is then rotated, as shown.

q16b-1-wph12-02-june-2021-edexcel-int-as-a-level-phy

Sketch a graph to show how the intensity of light measured at the screen varies as the filter is rotated from 0° to 90°.

q16b-2-wph12-02-june-2021-edexcel-int-as-a-level-phy

How did you do?

3c
Sme Calculator3 marks

Polarisation can be used to identify when some materials are under stress. Placing the material under stress causes the plane of polarisation of the light passing through the material to be rotated. The greater the stress, the greater the rotation of the plane of polarisation of the light.

A piece of transparent material under stress is positioned between two polarizing filters. There is an angle of 90o between the planes of polarisation of the two polarising filters.

q16c-wph12-02-june-2021-edexcel-int-as-a-level-phy

Explain how this photograph can be used to identify areas of the material with different amounts of stress.

How did you do?

Did this page help you?

4a
Sme Calculator2 marks

Light is a transverse wave.

Describe the difference between transverse waves and longitudinal waves.

How did you do?

4b
Sme Calculator8 marks

Two prisms, A and B, made from different types of glass are placed in contact as shown. An incident ray of light enters prism A.

q16b-wph12-02-jan-2022-edexcel-int-as-a-level-phy

i) State why the incident ray of light does not change direction as it enters prism A.

(1)

ii) The refractive index of the glass in prism B is greater than the refractive index of the glass in prism A. When the ray of light reaches the boundary between the prisms, some light is reflected and some is refracted.

Complete the diagram to show the two paths taken by the reflected and refracted light until they have returned to the air.

(4)

iii) Calculate the angle of refraction as this ray of light travels across the boundary between prism A and prism B.

refractive index of glass in prism A = 1.40

refractive index of glass in prism B = 1.55

Angle of refraction = .............................(3)

How did you do?

4c
Sme Calculator2 marks

The light emerging from prism B is observed through a polarising filter. The polarizing filter is rotated gradually, and the light transmitted by the filter varies in intensity.

Explain how this observation demonstrates that light waves are transverse.

How did you do?
