Electrophilic Substitution Mechanism

  • Benzene undergoes electrophilic substitution reactions

    • The hydrogen atom is substituted by the electrophile

  • You must be able to provide the mechanisms for specific examples of the electrophilic substitution of benzene including:

    • Nitration

    • Sulfonation

    • Friedel–Crafts Reactions

  • The electrophilic substitution reaction in arenes consists of three steps:

    • Generation of an electrophile

    • Electrophilic attack

    • Regenerating aromaticity

General Electrophilic Substitution Mechanism:

General electrophilic substitution mechanism 2, downloadable AS & A Level Chemistry revision notes
7-4-1-general-electrophilic-substitution-mechanism-1-1
The mechanism for nitration, sulfonation and Friedel–Crafts reactions follow the same pattern

Nitration

  • The nitration of benzene is one example of an electrophilic substitution reaction

    • A hydrogen atom is replaced by a nitro (-NO2) group

  • This is an important step in the:

    • Manufacture of explosives, like trinitrotoluene (TNT)

    • Formation of amines, which, in turn, are used to make dyes and pharmaceuticals

Nitration of benzene

Hydrocarbons - Overall Nitration, downloadable AS & A Level Chemistry revision notes
The overall reaction of nitration of arenes
  • In the first step, the NO2+ electrophile is generated

    • This is done by reacting concentrated nitric acid (HNO3) and concentrated sulfuric acid (H2SO4)

  • The nitrating mixture of HNO3 and H2SO4 is refluxed with the arene at 25 - 60 oC

  • Once the electrophile has been generated, it will carry out an electrophilic attack on the benzene ring

  • The intermediate formed loses a proton to regenerate its aromaticity

    • The proton is then used to reform the H2SO4 catalyst

Nitration of Benzene Mechanism:

Diagram to show the nitration of benzene
The electrophilic substitution mechanism for the nitration of benzene

Sulfonation

  • Another example of a substitution reaction is the sulfonation of arenes

  • In these reactions, a sulfonyl group (-SO3H) replaces a hydrogen atom on the arene

Sulfonation of benzene

benzene-sulfonation-equation
  • In the first step, an SO3 electrophile is generated by:

H2SO4 ⇌ SO3 + H2O

  • The benzene is warmed with a fuming sulfuric acid at a temperature of 40 oC for around 30 minutes

    • Fuming sulfuric acid is made by dissolving sulfur trioxide in concentrated sulfuric acid

  • Due to the electronegativity of the oxygen atoms, the SO3 is polarised

A diagram to show the structure of the SO3 molecule
The sulfur trioxide molecule is polarised
  • Once the electrophile has been generated, it will carry out an electrophilic attack on the benzene ring

  • The intermediate formed loses a proton to regenerate its aromaticity

The mechanism of sulfonation

A diagram to show the mechanism for the sulfonation of benzene
The mechanism for the sulfonation of benzene to form benzenesulfonic acid

Friedel–Crafts Reactions

  • Friedel-Crafts reactions are also electrophilic substitution reactions

  • Due to the aromatic stabilisation in arenes, they are often unreactive

  • To use arenes as starting materials for the synthesis of other organic compounds, their structure, therefore, needs to be changed to turn them into more reactive compounds

  • Friedel-Crafts reactions can be used to substitute a hydrogen atom in the benzene ring for an alkyl group (Friedel-Crafts alkylation) or an acyl group (Friedel-Crafts acylation)

  • Like any other electrophilic substitution reaction, the Friedel-Crafts reactions consist of three steps:

    • Generating the electrophile

    • Electrophilic attack on the benzene ring

    • Regenerating aromaticity of the benzene ring

Alkylation and Acylation Reactions

Hydrocarbons - Alkylation vs Acylation, downloadable AS & A Level Chemistry revision notes
Examples of Friedel-Crafts alkylation and acylation reactions

Friedel-Crafts Acylation

  • In the Friedel-Crafts acylation reaction, an acyl group is substituted into the benzene ring

    • An acyl group is an alkyl group containing a carbonyl, C=O group

  • The benzene ring is reacted with an acyl chloride in the presence of an AlCl3 catalyst

  • An example of an acylation reaction is the reaction of methylbenzene with propanoyl chloride to form an acyl benzene

    • Note that the acyl group is on the 4 position due to the -CH3 group on the benzene

The mechanism of Friedel-Crafts acylation

hydrocarbons-friedel-crafts
hydrocarbons-friedel-crafts
Example of a Friedel-Crafts acylation reaction
