Momentum (Cambridge (CIE) IGCSE Physics)

Extended tier only

A tennis player is practicing by hitting a ball many times against a wall.   The ball hits the wall 20 times in 60 s.

The average change in momentum for each collision with the wall is 4.2 kg m/s.

Calculate the average force that the ball exerts on the wall.

Extended tier only

The velocity of an object of mass m increases from u to v.

State, in terms of m, u and v, the change of momentum of the object.

Extended tier only

In a game of tennis, a player hits a stationary ball with his racquet.

(i) The racquet is in contact with the ball for 6.0 ms. The average force on the ball during this time is 400 N.

Calculate the impulse on the tennis ball.

impulse = ...........................................................[2]

(ii) The mass of the ball is 0.056 kg.

Calculate the speed with which the ball leaves the racquet.

speed = ...........................................................[2]

(iii) State the energy transfer that takes place:

  1. as the ball changes shape during the contact between the racquet and the ball

2. as the ball leaves the racquet.

[2]

Extended tier only

Complete Fig. 2.1 by writing in the right-hand column the name of the quantity given by the product in the left-hand column.

Fig 2.1

Extended tier only

Fig. 2.2 shows a man hitting a ball with a golf club.

The ball has a mass of 0.046 kg. The golf club is in contact with the ball for 5.0 × 10^–4 s and the ball leaves the golf club at a speed of 65 m/s.

(i) Calculate:

1. the momentum of the ball as it leaves the golf club

momentum = ...........................................................[2]

2. the average resultant force acting on the ball while it is in contact with the golf club.

average force = ...........................................................[2]

(ii) While the golf club is in contact with the ball, the ball becomes compressed and changes shape.

Name the energy store being filled whilst the ball is in contact with the golf club.

[1]

Extended tier only

Fig. 3.1 shows a shooting competition, where air rifles fire soft metal pellets at distant targets.

When an air rifle is fired, it exerts an impulse of 0.019 N s on the pellet.

Define impulse.

Extended tier only

The pellet has a mass of 1.1 × 10^–4 kg.

Determine:

(i) the speed with which the pellet leaves the rifle

 speed = ........................................................ [2]

(ii) the kinetic energy of the pellet as it leaves the rifle.

kinetic energy = ........................................................ [3]

The pellet melts when it strikes the target.

Describe how the molecular structure of the liquid metal differs from that of the solid metal.

Extended tier only

State the equation for impulse in terms of the velocity of an object. Define the variables used.

Extended tier only

In a game of croquet, a player hits a ball which was initially at rest with a mallet.

The mallet has mass of 1.36 kg.

(i) The mallet is in contact with the ball for 11 ms. The average force on the ball during this time is 200 N.

Calculate the impulse on the croquet ball.

impulse = ...........................................................[3]

(ii) The mass of the ball is 0.450 kg.

Calculate the speed with which the ball leaves the mallet.

speed = ...........................................................[2]

Extended tier only

After making contact with the ball the mallet stops moving. Calculate the velocity of the mallet at the moment it hit the ball.

State the energy transfer that takes place:

 (i) As the ball changes shape during the contact between the mallet and the ball.

[2]

(ii) As the ball leaves the mallet.

[1]

Extended tier only

Fig. 2.1 shows an athlete crossing the finishing line in a race. As she crosses the finishing line, her speed is 10.0 m/s. She slows down to a speed of 4.0 m/s.

The mass of the athlete is 71 kg. Calculate the impulse applied to her as she slows down. Give your answer to 2 significant figures.

 impulse = ...............................................

Extended tier only

(i) Define impulse in terms of force and time.

[1]

(ii) The athlete takes 1.2 s to slow down from a speed of 10.0 m/s to a speed of 4.0 m/s.

  Calculate the average resultant force applied to the athlete as she slows down.

  force = ........................................................ [2]

Extended tier only

Calculate the force required to give a mass of 71 kg an acceleration of 6.4 m/s².

  force = ........................................................

Extended tier only

Fig. 2.1 shows a train.

The total mass of the train and its passengers is 750 000 kg. The train is travelling at a speed of 84 m/s. The driver applies the brakes and the train takes 80 s to slow down to a speed of 42 m/s.

Calculate the impulse applied to the train as it slows down.

impulse = .........................................................

Extended tier only

Calculate the average resultant force applied to the train as it slows down.

force = .........................................................

Suggest how the shape of a modern electric train helps it to travel at high speeds.

The train took 80 s to reduce its speed from 84 m/s to 42 m/s. Explain why, with the same braking force, the train takes less than 80 s to reduce its speed from 42 m/s to zero.

On a wet day, the train travels a greater distance before it stops along the same track. The train has the same speed of 84 m / s before the brakes are applied.

  Suggest a reason for this.

Extended tier only

Fig. 1 shows two railway trucks A and B travelling towards each other on the same railway line which is straight and horizontal.

Fig. 1

The trucks are involved in a collision. They join when they collide and then move together.

Truck A has a total mass of 27 000 kg and truck B has a total mass of 22 000 kg.

Just before the collision, truck A was moving at a speed of 3.6 m s^–1 and truck B was moving at a speed of 2.4 m s^–1.

Calculate the speed of the joined trucks immediately after the collision.

Extended tier only

During the collision each truck experiences an impulse acting on it.

(i) Calculate the impulse that acts on each truck during the collision.

[2]

(ii) State two possible units for your answer.

[2]

Extended tier only

The trucks come to a stop after 3.0 minutes.

Calculate the deceleration of the joined trucks.

Explain why two trucks on rail tracks stop moving after they have collided.

Extended tier only

A shell, of mass 30 g, is fired from the barrel of a rifle, of mass 1.9 kg, with a momentum 36 kg m/s.

State the total momentum of the rifle and the bullet before the rifle is fired and give a reason for your answer.

Extended tier only

Calculate the velocity of the shell just after the rifle is fired.

Extended tier only

Continue to calculate for the moment just after the rifle has been fired.

(i) Use the principle of conservation of momentum, and your answer to part (a), to state the total momentum of the rifle and the shell.

[2]

(ii) Calculate the recoil momentum of the rifle.

[4]

Extended tier only

The shell has a momentum of 9.8 kg m/s just before it hits a target.

It takes 4.5 ms for the bullet to the stopped by the target.

Calculate the average force needed to stop the bullet.

Extended tier only

Until the second half of the 20th century, cars were designed as strong rigid boxes, which designers thought would protect passengers in accidents. In fact, although average speeds were much slower than today, passengers were often very badly injured.

Modern cars are designed with safety features including 'crumple zones'. The crumple zones are at the front and rear of the car but do not include the passenger section. In a crash, the crumple zone is designed so that it deforms and bends. This is shown in Fig. 1.1.

The use of crumple zones explains why the front and rear of cars are badly damaged during accidents.

Use your knowledge of momentum and impulse forces to suggest why a car with a crumple zone protects the driver and passengers from serious injury better than one which is a strong, rigid box.

Extended tier only

Two cars are crash-tested, with crash test dummy 'drivers' wearing seatbelts, to assess the force reduction that crumple zones provide in a road-traffic accident.

Car A has a mass of 1200 kg and car B has a mass of 1500 kg.

Both cars have a driver of mass 70 kg and they both crash to a stop from an initial speed of 30 m/s.

At the moment of impact, the front ends of the cars crumple, taking different amounts of time to come to a stop. Car A takes 0.3 seconds to stop, while car B takes 0.7 seconds to stop.

Using this information, calculate the forces which would be experienced by the cars due to the impact.

 (i) For car A

Force = .................................... N [3]

(ii)

For car B

Force = .................................... N [2]
