Problem Solving with Differentiation

What is problem solving using differentiation?

  • You can use the same method of differentiating curves to find turning points to help with problems involving finding the maximum or minimum value of a quantity

    • These are called optimisation problems

  • Questions may use different variables

    • For example, A equals t cubed minus 12 t and fraction numerator straight d A over denominator straight d t end fraction equals 0

How do I apply differentiation to different contexts?

  • This is easiest explained using an example

Diagram of a cuboid with the width, length and height labelled.

  • Find the maximum volume, V m3, of the cuboid shown with width 2 m, length x m and height open parentheses 10 minus x close parentheses m

    • Find a formula for its volume in terms of x

    • Volume = width cross times length cross times height

      • V equals 2 x open parentheses 10 minus x close parentheses

    • Expand this into individual terms in x

      • V equals 20 x minus 2 x squared

      • This is a negative quadratic in x (it has an intersection shape)

  • The graph of V against x will have a maximum point when fraction numerator straight d V over denominator straight d x end fraction equals 0

    • Find fraction numerator straight d V over denominator straight d x end fraction by differentiating each term

      • fraction numerator straight d V over denominator straight d x end fraction equals 20 minus 4 x

    • Set this equal to zero and solve

      • table row cell 20 minus 4 x end cell equals 0 end table so 4 x equals 20 giving x equals 5

      • This is the value of x at the maximum point (not the value of V)

    • Substitute this value of x back into the equation for V

      • V equals 20 cross times 5 minus 2 cross times 5 squared equals 50

      • The maximum volume is 50 m3

Examiner Tips and Tricks

A common problem in the exam is to forget to substitute the value of x back into the formula!

How do I know if I have found a maximum value or a minimum value?

  • Sometimes there are two values of x for different turning points and you need one of them

    • either substitute them both back into the formula

      • See which gives the max value and which gives the min value

    • or use any acceptable techniques for classifying turning points

      • For example, using a sketch to see if its a max or min

    • Remember that

      • Positive quadratics have minimum points

      • Negative quadratics have maximum points

How do I use differentiation if there are lots of variables?

  • Sometimes a formula has lots of letters

    • You need to find an extra relationship between these letters

    • then substitute it into the formula

  • If, in the above example, you had width 2 m, length x m and height y m then

    • V equals 2 x y

      • But you need a formula in x only

    • You will be given an extra piece of information, such as the length and height sum to 10 m

      • Therefore x plus y equals 10

      • Make y the subject, y equals 10 minus x

      • Substitute it into V to get V equals 2 x open parentheses 10 minus x close parentheses

Worked Example

A farmer has 60 metres of fencing and wants to fence off the biggest rectangular area possible next to an existing wall.

The area has dimensions x metres by y metres, as shown.

Image of the farmer's fence attached to a wall. There are three sides of fencing forming a rectangular area with the wall. The width of the rectangle is x and the length is y.

(a) Explain why 2 x plus y equals 60.

The wall is not part of the fencing

Find the total length of the three sides of the fence shown

x plus y plus x

This must equal 60 metres

The length of the fence must equal 60 metres so bold 2 bold italic x bold plus bold italic y bold equals bold 60

(b) Show that the area, Am2, is given by A equals 60 x minus 2 x squared.

Find the area of the rectangle shown

A equals x y

You need a right-hand side in terms of x only

Make y the subject of part (a)

y equals 60 minus 2 x

Substitute this into the area formula

A equals x open parentheses 60 minus 2 x close parentheses

This is now all in terms of x

Expand

bold italic A bold equals bold 60 bold italic x bold minus bold 2 bold italic x to the power of bold 2

(c) Find the maximum possible area.

To find a maximum point, set fraction numerator straight d A over denominator straight d x end fraction equals 0

First find fraction numerator straight d A over denominator straight d x end fraction by differentiating each term

fraction numerator straight d A over denominator straight d x end fraction equals 60 minus 4 x

Set this equal to zero and solve

table row cell 60 minus 4 x end cell equals 0 row cell 4 x end cell equals 60 row x equals cell 60 over 4 end cell row x equals 15 end table

This is the value of x at the maximum point (but not the maximum of A)

Substitute this value of x back into A

table row A equals cell 60 cross times 15 minus 2 cross times 15 squared end cell row blank equals 450 end table

The maximum area is 450 m2

(d) Explain how you know that the answer in part (c) is a maximum area, not a minimum area.

See how the area A depends on x

Think about what it would look like as a graph

A equals 60 x minus 2 x squared is a negative quadratic curve

A negative quadratic curve has an intersection shape

There is only one turning point on this graph and it is a maximum point

The curve bold italic A bold equals bold 60 bold italic x bold minus bold 2 bold italic x to the power of bold 2 is a negative quadratic curve

This means it can only have a maximum point, not a minimum point
