Right-Angled Triangles (Pythagoras & Trigonometry)

Select an answer set to view for
Right-Angled Triangles (Pythagoras & Trigonometry)

Medium
Hard
Very Hard
1a
Sme Calculator2 marks
q13-paper4-spec-2025-cie-igcse-further-maths

The diagram shows a quadrilateral, A B C D, formed from two triangles, A B C and A C D.

A B C is a right-angled triangle.

Calculate angle B A C.

Angle B A C = ..............................................

How did you do?

1b
Sme Calculator3 marks

Calculate the shortest distance from D to A C.

.......................................... cm

How did you do?

Did this page help you?

2
Sme Calculator3 marks
cie-igcse-2020-march-p2-tz2-q7a

The diagram shows a right-angled triangle.

Calculate the perimeter.

............................................ cm

How did you do?

Did this page help you?

3
Sme Calculator2 marks
cie-igcse-2019-may-june-1-q7

The diagram shows a right-angled triangle.

Calculate the value of x.

x = ............................................

How did you do?

Did this page help you?

4
Sme Calculator2 marks
UsCFLVj9_cie-icse-2018-may-jun-1-7

Calculate the length of AC.

AC = ........................................ cm

How did you do?

Did this page help you?

5
Sme Calculator2 marks
cie-igcse-2018-march-p2-16

Calculate AC.

AC = .................................... m

How did you do?

Did this page help you?

6
Sme Calculator3 marks

Here is a right-angled triangle.

q2-easy-4-10-right-angled-triangle-edexcel-gcse-maths

Work out the length of A C. Give your answer correct to 1 decimal place.

How did you do?

Did this page help you?

7
Sme Calculator3 marks
q3-easy-4-10-right-angled-triangle-edexcel-gcse-maths

L M N spaceis a right-angled triangle.

M N space= 9.6 cm.

L M= 6.4 cm.

Calculate the size of the angle marked x degree.

Give your answer correct to 1 decimal place.

How did you do?

Did this page help you?

8
Sme Calculator3 marks
q5-easy-4-10-right-angled-triangle-edexcel-gcse-maths

P Q R spaceis a right-angled triangle.

P R = 17 cm

P Q space= 25 cm

Work out the size of angle R P Q.

Give your answer correct to 1 decimal place.

How did you do?

Did this page help you?

9
Sme Calculator2 marks

A B C spaceis a right-angled triangle.

q6-easy-4-10-right-angled-triangle-edexcel-gcse-maths

Calculate the length of A B.

Give your answer correct to 3 significant figures.

How did you do?

Did this page help you?

10
Sme Calculator2 marks

P Q R spaceis a right-angled triangle.

q7-easy-4-10-right-angled-triangle-edexcel-gcse-maths

Work out the size of the angle marked x.

Give your answer correct to 1 decimal place.

How did you do?

Did this page help you?

11
Sme Calculator2 marks
cie-igcse-2020-oct-nov-p4-tz1-q4b

ABDF is a parallelogram and BCDE  is a straight line.

AF = 12cm, AB = 9 cm, angle CFD = 40° and angle FDE = 80°.

Calculate the height, h, of the parallelogram.



h space equals ........................................... cm

How did you do?

Did this page help you?

12a
Sme Calculator3 marks
cie-igcse-2018-oct-nov-p4-tz1-q5

The diagram shows a prism with length 18 cm and volume 253.8 cm3.

The cross-section of the prism is a right-angled triangle with base 6 cm and height h cm.

Show that the value of h is 4.7 .



How did you do?

12b
Sme Calculator2 marks

Calculate the value of x.

x = ...............................................

How did you do?

12c
Sme Calculator6 marks

Calculate the total surface area of the prism.

........................................ cm2

How did you do?

Did this page help you?

13
Sme Calculator5 marks
h0KYsqUX_cie-igcse-2018-oct-nov-p4-tz1-q10a

The diagram shows a circle, centre O.
The straight line ABC is a tangent to the circle at B.
OB = 8 cm, AB = 15 cm and BC = 22.4 cm.
AO crosses the circle at X and OC crosses the circle at Y.

Calculate angle XOY.

Angle XOY = .............................................

How did you do?

Did this page help you?

14
Sme Calculator2 marks
cie-igcse-2018-oct-nov-p4-tz3-q8a

In the diagram, AB and CD are parallel.
AD and BC intersect at right angles at the point X.
AB = 10 cm, CD = 5 cm, AX = 8 cm and BX = 6 cm.

Calculate angle XAB.



Angle XAB = ..............................................

How did you do?

Did this page help you?

15
Sme Calculator5 marks

Here is part of a field.

q3-medium-4-10-right-angled-triangle-edexcel-gcse-maths

This part of the field is in the shape of a trapezium.

A farmer wants to put a fence all the way around the edge of this part of the field.

The farmer has 50m of fence.

Does he have enough fence? You must show all your working.

How did you do?

Did this page help you?

16
Sme Calculator4 marks

The diagram shows a rectangular framework.

q4-medium-4-10-right-angled-triangle-edexcel-gcse-maths

The framework is made from 5 metal rods.

The metal rods have a weight of 0.9 kg per metre.

Work out the total weight of the framework.

Give your answer, in kg, correct to 3 significant figures.

How did you do?

Did this page help you?

17
Sme Calculator3 marks

The diagram shows a rectangle and a diagonal of the rectangle.

q4-4-ma1-2hr-qp-jan20-paper2-igcse-maths

Work out the length of the diagonal of the rectangle.

Give your answer correct to 1 decimal place.

.....................cm

How did you do?

Did this page help you?

1
Sme Calculator3 marks
cie-igcse-2018-may-jun-2-p2-q16

The diagram shows a circle, centre O.

AB is a chord of length 12 cm.

M is the mid-point of AB and OM = 4.5 cm.

Calculate the radius of the circle.

.......................................... cm

How did you do?

Did this page help you?

2
Sme Calculator4 marks

A B C spaceis an isosceles triangle.

q9-medium-4-10-right-angled-triangle-edexcel-gcse-maths

Work out the area of the triangle.

Give your answer correct to 3 significant figures.

How did you do?

Did this page help you?

3
Sme Calculator3 marks
q11-medium-4-10-right-angled-triangle-edexcel-gcse-maths

Calculate the length of P R.

Give your answer correct to 3 significant figures.

How did you do?

Did this page help you?

4a
Sme Calculator2 marks

A B C spaceis a right-angled triangle.

q7a-medium-4-10-right-angled-triangle-edexcel-gcse-maths

Work out the size of angle A B C.

Give your answer correct to 1 decimal place.

How did you do?

4b
Sme Calculator1 mark

The length of the side space A B spaceis reduced by 1 cm.

The length of the side space B C spaceis still 7 cm.

Angle space A C B spaceis still 90°

Will the value of cosspace A B C spaceincrease or decrease?

You must give a reason for your answer.

How did you do?

Did this page help you?

5
Sme Calculator2 marks

A solid metal cone has radius 1.65 cm and slant height 4.70 cm.

Find the angle the slant height makes with the base of the cone.

How did you do?

Did this page help you?

6
Sme Calculator2 marks
cie-igcse-2020-specimen-p4-q9a

The diagram shows a trapezium A B C D.

A B is parallel to D C.

A B space equals space 55 space straight m, B D space equals space 70 space straight m, angle A B D space equals space 40 degree and angle B C D space equals space 32 degree.

Calculate the shortest distance from A to B D.

 ............................................ m

How did you do?

Did this page help you?

7
Sme Calculator2 marks

The straight line A C has equation y equals 4 x plus 5.

Calculate the acute angle between A C and the x-axis.

How did you do?

Did this page help you?

8
Sme Calculator2 marks

In this question, all measurements are in metres.

cie-igcse-2018-may-jun-2-p4-q7

The diagram shows a right-angled triangle.

Given that x equals 3.82 to 3 significant figures, calculate the smallest angle of the triangle.

How did you do?

Did this page help you?

9a
Sme Calculator4 marks
cie-igcse-2018-may-jun-3-p4-q6a

In the pentagon A B C D E, angle A C B = angle A E D = 90°. Triangle A C D is equilateral with side length 12 cm.

D E = B C = 6 cm.

Calculate angle B A E.

Angle B A E = ...............................................

How did you do?

9b
Sme Calculator2 marks

Calculate A B.

A B = ......................................... cm

How did you do?

9c
Sme Calculator3 marks

Calculate A E.

A E = ......................................... cm

How did you do?

Did this page help you?

1
Sme Calculator5 marks
cie-igcse-2020-may-june-p2-tz1-q13

C lies on a circle with diameter A D.

B lies on A C and E lies on A D such that B E is parallel to C D.

A B = 21 cm, C D = 18 cm and B E = 13.5 cm.

Work out the radius of the circle.

............................................ cm

How did you do?

Did this page help you?

2
Sme Calculator3 marks

Point A has co-ordinates (1, 0) and point B has co-ordinates (2, 5).

Calculate the angle between the line AB and the x-axis.

How did you do?

Did this page help you?

3
Sme Calculator4 marks

A square, with sides of length x cm, is inside a circle. Each vertex of the square is on the circumference of the circle.

The area of the circle is 49 cm2.

Work out the value of x.

Give your answer correct to 3 significant figures.

How did you do?

Did this page help you?

4
Sme Calculator5 marks

Here is triangle A B D.

q10-paper1h-jan2019-edexcel-igcse-maths

The point C lies on B D.

A D space equals space 13 cm space space space space space space B C space equals space 8 cm space space space space space space space angle space A D B space equals space 90 degree space space space space space space angle space C A D space equals space 20 degree

Calculate the size of angle B A C.

Give your answer correct to 1 decimal place.

How did you do?

Did this page help you?

5
Sme Calculator3 marks
cie-igcse-2020-may-june-p4-tz1-q7

The diagram shows the positions of three points A, B and C in a field.

Calculate the shortest distance from point B to A C.

............................................. m

How did you do?

Did this page help you?

6
Sme Calculator6 marks
cie-igcse-2020-may-jun-p4-tz2-q5

The diagram shows a field ABCD.

The bearing of B from A is 140°.

C is due east of B and D is due north of C.

AB = 400m, BC = 350m and CD = 450m.

Calculate the distance from D to A.

 ............................................. m

How did you do?

Did this page help you?

7
Sme Calculator2 marks
cie-igcse-2019-oct-nov-p4-tz1-q5a

The angle B A C is 82.8 degree correct to 3 significant figures.

D is the point on AC that is nearest to B.

Calculate the distance from D to A.

................................................ m

How did you do?

Did this page help you?

8
Sme Calculator4 marks
cie-igcse-2020-may-jun-p4-tz1-q3

The diagram shows a field ABCDE.

Calculate the perimeter of the field ABCDE.

................................................ m

How did you do?

Did this page help you?

9
Sme Calculator3 marks
cie-igcse-2019-may-jun-p4-tz3-q9a

In the diagram, B C is a vertical wall standing on horizontal ground A B. A C = 76.7 m.

D is the point on A B where A D = 58 m.

The angle of elevation of C from A is 26°.

The angle of elevation of C from D is 72°.

Calculate B D.

B D = .......................................... m

How did you do?

Did this page help you?
