Angles in Polygons & Parallel Lines (Edexcel GCSE Maths: Foundation)

Exam Questions

2 hours40 questions
Easy
Medium
Hard
1
Sme Calculator2 marks
qp11-0580-13-paper-1-may-2020-cie-igcse-maths-1

Triangle A B C is isosceles.
Angle A B C = 32° and A B space equals space A C.

Find angle B A C.

Angle B A C = .................................................

How did you do?

Did this page help you?

2
Sme Calculator2 marks
qp4-0580-12-paper-1-march-2020-cie-igcse-maths

Work out the value ofspace x.
Give a geometrical reason for your answer.

x = .................... because .......................................................................

How did you do?

Did this page help you?

3
Sme Calculator1 mark

A student measures the angles in a triangle as 55°, 85° and 50°.

Explain why the student is incorrect.

How did you do?

Did this page help you?

4
Sme Calculator2 marks
qp7a-0580-32-paper-3-may-2020-cie-igcse-maths

The diagram shows an isosceles triangle.

Find the value of x.

x space= .................................................

How did you do?

Did this page help you?

5
Sme Calculator1 mark

A B C is a straight line.

qp3b-0580-31-paper-3-oct-nov-2019-cie-igcse-maths

Find the value of y.

y space equals ...................................................

How did you do?

Did this page help you?

6
Sme Calculator2 marks

Work out the size of one interior angle of a regular 16-sided polygon.

How did you do?

Did this page help you?

7
Sme Calculator2 marks

Work out the size of one interior angle of a regular 9-sided polygon.

How did you do?

Did this page help you?

8
Sme Calculator1 mark

i) Write down the mathematical name for an 8-sided polygon.

[1]

ii) Work out the size of an interior angle of a regular 24-sided polygon.

[2]

How did you do?

Did this page help you?

9
Sme Calculator3 marks

Find the size of one interior angle of a regular octagon.

How did you do?

Did this page help you?

10a
Sme Calculator1 mark
q8-058012-mayjune2019-cie-igcse-maths-core

The diagram shows two parallel lines and a straight line crossing them.

Write down, using letters from a to g,

the angle that is alternate to angle X,

How did you do?

10b
Sme Calculator1 mark

the angle that is corresponding to angle X.

How did you do?

Did this page help you?

11
Sme Calculator3 marks

Find the size of one interior angle of a regular 10-sided polygon.

How did you do?

Did this page help you?

12
Sme Calculator3 marks

Work out the size of one interior angle of a regular polygon with 20 sides.

How did you do?

Did this page help you?

1
Sme Calculator2 marks
qp7a-0580-31-paper-3-nov-2020-cie-igcse-maths

The diagram shows an isosceles triangle and a straight line.
Work out the value of w.

w equals...............................[2]

How did you do?

Did this page help you?

2
Sme Calculator3 marks
qp8b-0580-03-paper-3-specimen-2020-cie-igcse-maths

Work out the value of w.
Give reasons for your answer.

w space equals ............................ because ....................................................................................................

How did you do?

Did this page help you?

3
Sme Calculator2 marks

Q R S spaceis an isosceles triangle and P Q R is a straight line.

qp3c-0580-31-paper-3-oct-nov-2019-cie-igcse-maths

Find the value of z.

z = ...................................................

How did you do?

Did this page help you?

4
Sme Calculator2 marks
q4a-058031-mayjune2019-cie-igcse-maths-core

A B C is an isosceles triangle.
B C D is a straight line.

Find the value of a.

a = ..............................................

How did you do?

Did this page help you?

5
Sme Calculator2 marks
qp2c-0580-32-paper-3-nov-2020-cie-igcse-maths

A B C spaceis a straight line and B C D is an isosceles triangle.
Find the value ofspace x.

x space= .................................................

How did you do?

Did this page help you?

6
Sme Calculator3 marks
qp5-0580-11-paper-1-may-2020-cie-igcse-maths

In the triangle A B C comma space A B space equals space A C and angle B A C space equals space 38 degree.

B C D spaceis a straight line.

Work out angle A C D.

Angle A C D = ..................................................

How did you do?

Did this page help you?

7a
Sme Calculator1 mark

A triangle is isosceles.
One of its angles is 96°.

Find the other two angles.

........................ and ........................

How did you do?

7b
Sme Calculator4 marks
q7b-058032-mayjune2019-cie-igcse-maths-core

Find the value of x.

x = ...................................................

How did you do?

Did this page help you?

8
Sme Calculator3 marks
qp10-0580-12-paper-1-nov-2020-cie-igcse-maths

The diagram shows a triangle drawn between a pair of parallel lines.

Find the value of x and the value of y.

x space equals space.............................. y space equals space..............................

How did you do?

Did this page help you?

9
Sme Calculator1 mark

A regular polygon has an exterior angle of 20°.

Work out the number of sides of this polygon.

How did you do?

Did this page help you?

10
Sme Calculator6 marks
qp8b-0580-33-paper-3-nov-2020-cie-igcse-maths

The diagram shows two parallel lines and two straight lines.

i) Find the value of a.

Give a reason for your answer.

a = ................ because ..................................................................................................... [2]

ii) Find the value of b.
Give a reason for your answer.

b = ................ because ......................................................................................................[2]

iii) Find the value of c.

c = ................................................. [2]

How did you do?

Did this page help you?

11a
Sme Calculator2 marks
qp8-0580-13-paper-1-may-2020-cie-igcse-maths

In the diagram, A B is parallel to C D.

Find the value ofspace x.
Give a geometrical reason for your answer.

x= ......................... because ....................................

How did you do?

11b
Sme Calculator2 marks

Work out the value of y.
Give a geometrical reason for your answer.

y space equals.................because ......................

How did you do?

Did this page help you?

12
Sme Calculator2 marks
qp8a-0580-03-paper-3-specimen-2020-cie-igcse-maths

Work out the value of

i) x comma

x=..........................[1]

ii) y.

y space equals...........................[1]

How did you do?

Did this page help you?

13
Sme Calculator3 marks

The diagram shows a triangle between two parallel lines, A B and C D.

qp7b-0580-33-paper-3-oct-nov-2019-cie-igcse-maths

Find the value of

i) v comma

v=............................. [1]

ii) w comma

w equals............................. [1]

iii) y.

y = .............................  [1]

How did you do?

Did this page help you?

14
Sme Calculator4 marks
q20-058012-march2018-cie-igcse-maths-core

Complete the statements.

a space equals ............................ because ............................

b space equals ........................... because ............................

How did you do?

Did this page help you?

1
Sme Calculator3 marks

The diagram shows a trapezium.

qp14-0580-11-paper-1-may-2020-cie-igcse-maths

Work out the value of x.

x = ..................................................

How did you do?

Did this page help you?

2
Sme Calculator2 marks

Kim knows that one angle of an isosceles triangle is 48°.
He says that one of the other angles must be 66°.

Explain why Kim is wrong.

How did you do?

Did this page help you?

3
Sme Calculator4 marks
qp5b-0580-32-paper-3-oct-nov-2019-cie-igcse-maths

The diagram shows triangle P R S and a straight line Q S. Q is a point on P R.
Angle Q R S = 25°, angle R S Q = 32° and P S space equals space Q S.

i) Find angle P Q S.

Angle P Q S = ................................................... [2]

ii) Find angle P S R.

Angle P S R = ................................................... [2]

How did you do?

Did this page help you?

4
Sme Calculator4 marks

The diagram shows a triangle.

q8e-058031-octnov2018-cie-igcse-maths-core

Use the diagram to write down an equation and solve it to find the value of x.

x = .................................. [4]

How did you do?

Did this page help you?

5
Sme Calculator2 marks
q5d-058032-octnov2018-cie-igcse-maths-core

The diagram shows an isosceles triangle, A B C.
B C D is a straight line.

Find the value of x.

x space equals ................................ [2]

How did you do?

Did this page help you?

6
Sme Calculator2 marks
qp7b-0580-31-paper-3-nov-2020-cie-igcse-maths

A B C D is a rectangle.
A E is parallel to D B F.

Find the value of x and the value of y.

x = ......................................................
y = ................................................. .....

How did you do?

Did this page help you?

7
Sme Calculator3 marks
qp7d-0580-31-paper-3-nov-2020-cie-igcse-maths

Two regular octagons and a square meet at point P.
Show, by calculation, that the three interior angles at P add up to 360°.

How did you do?

Did this page help you?

8
Sme Calculator3 marks
qp7b-0580-32-paper-3-may-2020-cie-igcse-maths

The diagram shows two pairs of parallel lines.

Find the value of a, the value of b and the value of c.

a space equals space................................................. space b space equals space................................................. space c space equals space................................................. space

How did you do?

Did this page help you?

9
Sme Calculator4 marks

The diagram shows part of a different regular polygon.

qp7b-0580-33-paper-3-may-2020-cie-igcse-maths

e is an exterior angle.
i is an interior angle.
The ratio e space colon space i equals 2 colon 13.

i) Work out angle e.

[3]

ii) Work out the number of sides of this regular polygon.

[1]

How did you do?

Did this page help you?

10
Sme Calculator1 mark
qp13-0580-01-paper-1-specimen-2020-cie-igcse-maths

A B C D E is a pentagon.


Explain why the diagram shows that the sum of the interior angles of a pentagon is 540°.
Do not measure any angles.

How did you do?

Did this page help you?

11
Sme Calculator2 marks
q4d-058031-mayjune2019-cie-igcse-maths-core

In the diagram space A G spaceand A F are straight lines.
Lines B C and D E are parallel.

Find angle C E D and give a reason for your answer.

Angle C E D = ................................. because ...................................

How did you do?

Did this page help you?

12
Sme Calculator4 marks
q23-058013-mayjune2019-cie-igcse-maths-core

The diagram shows two regular pentagons.
Pentagon F G H J K is an enlargement of pentagon A B C D E, centre O.

Find angle A E K.

Angle A E K = ..............................

How did you do?

Did this page help you?

13
Sme Calculator8 marks
q6a-058033-mayjune2019-cie-igcse-maths-core

In the diagram, A B C is a straight line. A D is parallel to B E, angle B A D = 34° and A B space equals space B D.

i) Complete the statements.

a) p space equals ................ because ................................

[2]

b) q space equals ................ because .................................

[2]

ii) Work out the value of r and the value of s.

r space equals space....................
  s space equals .................... [2]

iii) Find the value of t and give a reason for your answer.

t space equals................ because ........................

[2]

How did you do?

Did this page help you?

14
Sme Calculator3 marks

Each interior angle of a regular polygon is 162°.

Calculate the number of sides of the polygon.

How did you do?

Did this page help you?
