Electric Current (CIE AS Physics)

Exam Questions

1 hour25 questions

Select a question set to download for
9.1 Electric Current

Select an answer set to view for
9.1 Electric Current

Easy
Medium
1a
Sme Calculator2 marks

Define the amp.

How did you do?

1b
Sme Calculator2 marks

A charge of 60 × 10–6 C flows through a given section of a conductor in 140 × 10–3 s. Calculate the electric current, stating the final answer in mA.

How did you do?

1c
Sme Calculator4 marks

Use words from the list below to complete the description of the movement of charge carriers in a conductor.

average current delocalised electric force
electric field randomly drift

The charge carriers in a metal conductor are ...................... electrons.

Normally the electrons move ..................... in all directions, but if a potential difference is applied between two points on the conductor, then an ..................... is created.

This causes an ..................... to act on the charge carriers, causing them to ..................... along the conductor in a resultant direction.

Therefore we can say that a steady ..................... flows through the conductor.

How did you do?

1d
Sme Calculator3 marks

The conductor described in part (a) has a cross-sectional area of 1.1 × 10−7 m2 and the electrons have an average drift speed of 18 mm s−1.

Calculate the number density of electrons in this conductor.

How did you do?

Did this page help you?

2a
Sme Calculator2 marks

The Standard International System of Units (SI) is a system of measurement based on seven base units.

State the symbol and the SI unit for electric charge.

How did you do?

2b
Sme Calculator2 marks

In a circuit, a current of 2.0 A flows through a resistor for 90 minutes.

Calculate the total charge passing through the resistor in this time.

How did you do?

2c
Sme Calculator2 marks

Determine the number of electrons that pass a point in the resistor in part (b).

How did you do?

2d
Sme Calculator3 marks

When a copper wire is exposed to a potential difference, a current is detected in it.

Explain, with reference to charge carriers and electric fields, why there is a current detected in the wire.

How did you do?

Did this page help you?

3a
Sme Calculator3 marks

Electric current is defined as the rate of flow of electric charge.

(i)
State the particle responsible for carrying electric charge around a circuit

[1]

(ii)
Calculate the total electric charge carried by ten million of these particles

[2]

How did you do?

3b
Sme Calculator3 marks

A lamp forms part of a circuit. A current of 0.3 mA passes through the lamp for a period of 5 minutes.

Calculate the amount of charge which passes a point in the lamp over those 5 minutes.

How did you do?

3c
Sme Calculator2 marks

A section of wire in the lamp in part (b) has a cross-sectional area of 4.5 × 10−5 m2.

If the number density of electrons in this section of wire is 3.6 × 1022 m−3, then calculate the average drift velocity of the electrons.

How did you do?

3d
Sme Calculator3 marks

Fig. 1.1 shows a typical electric circuit involving a battery, lamp and two resistors.

There is a gap in the circuit between points X and Y.

5-1-s-q--q1b-easy-aqa-a-level-physics

Fig. 1.1

Draw on Fig. 1.1:

(i)
An ammeter between X and Y that would measure the current in the circuit

[1]

(ii)
The direction of conventional current in the circuit

[2]

How did you do?

Did this page help you?

1a
Sme Calculator4 marks

The smallest conductor within a computer processing chip can be represented as a rectangular block that is one atom high, four atoms wide and twenty atoms long. One such block is shown in Fig. 1.1.

9-1-2a-m-conducting-chip

Fig. 1.1.

The block is made from phosphorus atoms of diameter d = 3.8 × 10–10 m. The atoms are deposited on an insulating surface. This ensures that the atoms touch each other.

The processing chip has a resistance, measured from P to Q, of 220 Ω.

(i)
Define current.
[1]
(ii)
Describe for this processing chip the properties which will affect the current.
[3]

How did you do?

1b
Sme Calculator1 mark

Calculate the number density of free electrons within the block.

Assume that each phosphorus atom contributes one free electron.

How did you do?

1c
Sme Calculator3 marks

Calculate the current between P and Q when the mean drift velocity of free electrons in the block is 1.9 × 10–5 ms–1.

How did you do?

1d
Sme Calculator3 marks

There are about 109 of these tiny conductors in a single chip each carrying the current calculated in part (c).

Estimate the total power dissipated in these conductors in a single chip.

How did you do?

Did this page help you?

2a
Sme Calculator1 mark

A power source is connected across a component. The current in the component is 40 mA.

Calculate the total charge that flows past a point in the component in 3 minutes.

How did you do?

2b
Sme Calculator1 mark

Calculate the number of electron charge carriers passing the same point in the conductor in this time.

How did you do?

2c
Sme Calculator4 marks

8.6 J of energy are transferred to the conductor in this time.

(i)
Calculate the potential difference across the component.
[2]
(ii)
Calculate the resistance of the conductor.
[2]

How did you do?

Did this page help you?

3a
Sme Calculator2 marks

Nancy is testing a new type of light bulb. She records the amount of current and the relative brightness of the light coming from the bulb.

Sketch a possible circuit diagram to show this experimental setup.

How did you do?

3b
Sme Calculator3 marks

Explain why the ammeter needs to be connected in series.



How did you do?

3c
Sme Calculator3 marks

Explain the results Nancy should expect to obtain, assuming the resistance of the bulb, ammeter and circuit remain constant.

How did you do?

3d
Sme Calculator2 marks

Nancy sets up her circuit and begins to conduct her experiment. Her first readings are negative values of current.

Identify the problem and suggest a solution.

How did you do?

Did this page help you?
