Photons & Wave-Particle Duality (OCR A Level Physics)

Exam Questions

15 mins5 questions

Select a question set to download for
Photons & Wave-Particle Duality

Select an answer set to view for
Photons & Wave-Particle Duality

Easy
Medium
11 mark

What can be deduced from the diffraction of electrons by a thin film of graphite?

  • Electrons are leptons.

  • Electrons are negatively charged.

  • Electrons interact with atoms on a one-to-one basis.

  • Electrons travel as waves.

Choose your answer

Did this page help you?

1
Sme Calculator1 mark

An electron has a de Broglie wavelength equal to the wavelength of X-rays.

What is the best estimate of the momentum of this electron?

  • 10−30 kg ms−1

  • 10−27 kg ms−1

  • 10−23 kg ms−1

  • 10−18 kg ms−1

Choose your answer

Did this page help you?

2
Sme Calculator1 mark

In an experiment the de Broglie wavelength of an electron after being accelerated through a potential difference (p.d) V is λ1.

The accelerating p.d is now tripled.

What is the new de Broglie wavelength of the electron in terms of λ1?

  • lambda subscript 1 over 3

  • fraction numerator lambda subscript 1 over denominator square root of 3 end fraction

  • square root of 3 lambda subscript 1

  • 3 lambda subscript 1

Choose your answer

Did this page help you?

3
Sme Calculator1 mark

A neutron has a kinetic energy of 9.00 x 10−18 J.

Which is the correct expression for the de Broglie wavelength λ of the neutron?

  • lambda equals fraction numerator 6.63 cross times 10 to the power of negative 34 end exponent over denominator 2 cross times 1.675 cross times 10 to the power of negative 27 end exponent cross times 9.00 cross times 10 to the power of negative 18 end exponent end fraction

  • lambda equals fraction numerator 6.63 cross times 10 to the power of negative 34 end exponent over denominator 2 cross times 9.11 cross times 10 to the power of negative 31 end exponent cross times 9.00 cross times 10 to the power of negative 18 end exponent end fraction

  • lambda equals fraction numerator 6.63 cross times 10 to the power of negative 34 end exponent over denominator square root of 2 cross times 1.675 cross times 10 to the power of negative 27 end exponent cross times 9.00 cross times 10 to the power of negative 18 end exponent end root end fraction

  • lambda equals fraction numerator 6.63 cross times 10 to the power of negative 34 end exponent over denominator square root of 2 cross times 9.11 cross times 10 to the power of negative 31 end exponent cross times 9.00 cross times 10 to the power of negative 18 end exponent end root end fraction

Choose your answer

Did this page help you?
