Nuclear Magnetic Resonance Spectroscopy (AQA A Level Chemistry)

Exam Questions

3 hours30 questions

Select a question set to download for
Nuclear Magnetic Resonance Spectroscopy

Select an answer set to view for
Nuclear Magnetic Resonance Spectroscopy

Easy
Medium
Hard
11 mark

The IUPAC name of mellitene, C6(CH3)6, is 1,2,3,4,5,6-hexamethylbenzene.

What splitting pattern will be seen on the 1H NMR spectrum for mellitene?

  • Singlet

  • Doublet

  • Triplet

  • Quartet

Choose your answer

Did this page help you?

21 mark

N-phenylethanamide, shown below, was used as a painkiller until the discovery of paracetamol.

7-10-e-q2-aqa-al-chemistry

 How many 13C peaks are in the spectrum of N-phenylethanamide?

  • 5

  • 6

  • 7

  • 8

Choose your answer

Did this page help you?

31 mark

Which of the following chemicals has a singlet peak in its 1H NMR spectrum?

  • 7-10-e-q3-a-aqa-al-chemistry
  • 7-10-e-q3-b-aqa-al-chemistry
  • 7-10-e-q3-c-aqa-al-chemistry
  • 7-10-e-q3-d-aqa-al-chemistry

Choose your answer

Did this page help you?

41 mark

The structure of 2-chloropropane is shown below.

7-10-e-q4-aqa-al-chemistry

Which description of the peaks in the 1H NMR spectrum of 2-chloropropane is correct?

  • 1 peak with a relative intensity of 6

  • 2 peaks with relative intensities of 3 : 4

  • 3 peaks with relative intensities of 3 : 1 : 3

  • 2 peaks with relative intensities 6 : 1

Choose your answer

Did this page help you?

51 mark

How many peaks will be shown in the low resolution 1H NMR spectrum of propanal?

7-10-e-q5-aqa-al-chemistry

  • 2

  • 3

  • 4

  • 6

Choose your answer

Did this page help you?

11 mark

How many peaks are there in the 13C NMR spectrum of 1,3-dimethylbenzene?

  • 3

  • 4

  • 5

  • 8

Choose your answer

Did this page help you?

21 mark

Which one of the following has the fewest peaks in its 1H NMR spectrum?

  • Pentan-3-one

  • 2-bromobutane

  • N-ethylethanamide

  • Ethyl ethanoate

Choose your answer

Did this page help you?

31 mark

How many peaks does benzopyran have in its 13C NMR spectrum?

7-10-m-q3-aqa-al-chemistry

  • 5

  • 6

  • 8

  • 9

Choose your answer

Did this page help you?

41 mark

Which one of the following has a doublet peak in its 1H NMR spectrum?

  • Pentan-3-one

  • 2-bromobutane

  • N-ethylethanamide

  • Ethyl ethanoate

Choose your answer

Did this page help you?

51 mark

Which row correctly describes the splitting pattern observed on the 1H NMR spectrum for each labelled hydrogen?

7-10-m-q5-aqa-al-chemistry

A

One doublet and four triplets

B

One triplet, one quartet and one singlet

C

One triplet, one doublet and three singlets

D

One triplet, one quartet and three singlets

    Choose your answer

    Did this page help you?

    11 mark

    How many signals would be found in the 1H NMR spectrum of pentan-3-ol and what would be the ratio of the peak areas?





    Signals

    Ratio of peak areas

    A

    4

    6 : 4 : 1 : 1

    B

    6

    3 : 3 : 2 : 2 : 1 : 1

    C

    4

    3 : 2 : 1 : 1

    D

    4

    5 : 5 : 1 : 1

      Choose your answer

      Did this page help you?

      21 mark

      Which compound could the following 1H NMR spectrum belong to?

      7-10-h-q2-aqa-al-chemistry
      7-10-h-q2abcd-aqa-al-chemistry

        Choose your answer

        Did this page help you?

        31 mark

        Penguinone is a cyclic ketone with a cute resemblance to a penguin:

        7-10-h-q3-aqa-al-chemistry



        Which row shows the correct number of peaks, peak area ratios and splitting patterns in the 1H NMR spectrum of penguinone? (s= singlet, t= triplet, q= quartet, m= multiplet)



        Peaks

        Peak Area Ratios

        Splitting patterns

        A

        4

        3 : 3 : 3 : 3

        t, t, q, q

        B

        2

        6 : 6

        s, s

        C

        3

        3 : 6 : 3

        m, q, m

        D

        3

        3 : 3 : 1

        s, s, s

          Choose your answer

          Did this page help you?

          41 mark

          Which molecule gives the same number of peaks in its 1H and 13C NMR spectrum?





          propanal

          pentan-3-one

          1,2-dimethylbenzene

          A

          ✓

          ✓

          ✓

          B

          ✓

          ✓

          x

          C

          x

          ✓

          ✓

          D

          ✓

          x

          x

            Choose your answer

            Did this page help you?

            51 mark

            The monomer used to make perspex is methyl methacrylate.



            7-10-h-q51-aqa-al-chemistry

            The 13C NMR spectrum of methyl methacrylate is show below



            7-10-h-q52-aqa-al-chemistry



            What is the correct identity of the carbon labelled in peak 3? (You need to use a table of 13C chemical shift values to answer this question).

            • -C-CH3

            • -COOCH3

            • -O-CH3

            • =C-CH3

            Choose your answer

            Did this page help you?
